Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal
Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal
Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal
Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal

Serial Number: NanoCortex

Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal

Condition: New

$569.00 $499.00
/
  • In stock, ready to ship

SHIPPING

All of our orders are shipped with UPS and signature required at delivery (excluding small accessories).

Orders placed before 2PM EST will ship same-day.

You will receive a tracking number as soon as your order ships. Please note: All delivery changes (hold for pickup, address change, etc.) must be requested before your order leaves our store, otherwise, they are the responsibility of the customer.

RETURNS

You can return an item for any reason up to 5 days from receipt of the item, with the exception of international orders or instruments that have been modified at the customer's request. You will need to pay the return shipping cost and outgoing shipping cost (even if “free shipping” is offered), as well as applicable restocking fees dependent on your payment method (usually a 3-10% fee, specific amounts can be found at the link below).

We highly recommend reviewing our full return policy before purchasing so there are no surprises.

Unfortunately due to the complex nature of accessory size and weights, we are unable to offer international shipping on our website, but can come up with a custom shipping quote for our international customers. Please contact us to get your quote!

Email us or call/text us at 315-447-3243

Make an appointment to visit our showroom

Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal

DESCRIPTION

Nano Cortex delivers studio-grade sound, a fully customizable signal chain, a complete suite of effects, and the revolutionary Neural Capture technology - all in a compact, ultra-portable pedal. Whether you’re on stage, in the studio, or anywhere in between, your perfect tone is always within reach.

Since its release, Neural Capture has transformed how players approach tone, delivering unmatched accuracy in capturing and replicating amps, cabs, and drive pedals. Artists and engineers alike have praised how real and responsive it feels to play.

Now, that same groundbreaking technology is packed into a travel-ready unit built for real-world use - wherever inspiration strikes.

Welcome to the future of portable, professional-grade tone.

SPECS

Dimensions: 14.4 × 10.3 × 6.2 cm (5.6 × 4.0 × 2.4 in)

Weight: 1.36 lbs

Processor: SHARC DSP (2 GHz)

Inputs / Outputs

  • ¼″ instrument input (1 MΩ)

  • XLR/¼″ combo input with +26 dB boost option

  • Dual ¼″ TRS main outputs (balanced/unbalanced)

  • 3.5 mm headphone out with volume control

  • USB-C (audio interface, 24-bit / 48 kHz, 4 in / 3 out)

  • TRS MIDI / expression input

  • Bluetooth for app control

Power

  • 9–12 V DC, 600 mA (center negative)

  • USB-C (5 V, ≥1.5 A)

Storage & Presets

  • 256 Neural Capture slots

  • 256 IR slots (10 premium preloaded)

  • 64 user presets

Effects & Signal Chain

  • Fixed layout with 7 blocks: input gate, 2 pre-FX, capture, IR loader, 3 post-FX

  • 50+ effects (drives, compression, EQ, modulation, delay, reverb, utility)

  • Global cab bypass option

Library

  • 20 guitar amp captures, 5 bass amp captures, drive pedals

  • 8 guitar cabs + 2 bass cabs with mic models and positions

Workflow & App

  • Works standalone (no app required)

  • Amp/pedal captures take ~5 minutes on-device

  • Cortex Cloud app via Bluetooth for presets, captures, firmware, and sharing
